Submersible Borehole Pumps
DC Solar Pumps
DC solar borehole pumps with permanent-magnet brushless motors for 4" boreholes.
Solar pumps, also known as photovoltaic water pumping systems, runs with the electricity generated by solar panels. lt is an attrac- tive water supply method in areas with abundant sunshine, espe- cially in remote areas with lacked electricity supply. lt takes ad- vantage of the sustainable solar energy to achieve efficient and reliable water supply. The pump can automatically operate accord- ing to sunrise, sunset, and weather conditions. lt requires no human supervision during daytime operation and the maintenance cost can be minimized. lt is a high-efficiency, green energy, and high-tech product that integrates economy, reliability, and envi- ronmental protection.
- Delivery
- Min: 0.6m3/h up to Max : 4.8m3/h
- Head
- Min: 18m up to Max: 145m
Choose a model
| Model | Power (kW) | Max head (m) | Max flow (m³/h) | Curves | Open |
|---|---|---|---|---|---|
| 4DP5-65-48-800 | |||||
| 4DP5-100-110-1100 | |||||
| 4DP5-150-110-1500 |
Specifications
- Maximum fluid temperature
- up to 35°C
- Maximum sand content
- 0.25%
- Minimum borehole diameter
- 4′′
Applications
- For water supply from wells or reservoirs
- For domestic use, for civil and industrial applications For garden use and irrigation.
- Permanent magnetic brushless DC motor NEMA Dimension standards
- Curve tolerance according to ISO9906 Over-load protection, under-load protection. Lock-rotor protection, thermal protection.
Need help sizing a DC Solar Pumps pump?
Send your flow and head and we will recommend the right model.
